VK-C6F VK-C30F VK-C60F VK-C120F 6W-120W 100V Volume Controller with Relay
100V Volume Controller 100V Volume Control Volume Attenuator Transformer Speaker Volume Controller Volume Controller with Relay100V Volume Controller 100V Volume Control Volume Attenuator Transformer Speaker Volume Controller Volume Controller with Relay
Feature:
- PA (Public address) system use 100V input volume control with full sealed back cover.
- Background music system use attenuator of waterproof finish for bathroom, washroom and SPA.
- The public address system volume controller is used to adjust the loudspeaker output in the room.
- The PA system volume controller is used to keep same output level for one same speaker line, because the end the speaker line signal loss is rather big, so its outputs is less, thus volume controller is added to the front of the line to lower the speaker output so as to keep the similar ambient output level for the all of the speaker in the same line.
- High level white UV-protected ABS material to integrate together with the white wall and architecture design.
- Built-in transformer to control the PA 100V line loudspeakers.
- With 10 levels of volume attenuator and one position of off.
- Wall plate with waterproof mounting box and front panel are separated fixed together.
- Surface wall mount or in-wall mounting box included.
- Option: models with F means with relay 24V and models with E means with priority input.
Specification:
Model | VK-C6 | VK-C30 | VK-C60 | VK-C120 |
Description | 100V Public Address System Volume Controller | |||
Rated Output | 6W | 30W | 60W | 120W |
Relay | No | |||
Line Input | 100V or 70V | |||
Volume Step | 10 steps plus off | |||
Attenuation Per Step | 3dB | |||
Total Attenuation | 33dB | |||
Material | UV-protected ABS in white | |||
Mounting Way | Surface mount or in-wall mount with supplied mounting box | |||
Dimension | 115(W)×70(D)×80(H)mm | |||
Weight | 150g | 250g | ||
