PA SYSTEM POWER SUPPLY SEQUENCE CONTALLER PA-308PS
PA System Speaker Zone SelectorUniversal socket，Power Supply,RS232 lamp，8-Channel Power Indicator Lamp，LCD screen，Total Power Supply
PA System Speaker Zone Selector
Feature:
- Universal socket
- Power Supply,RS232 lamp
- 8-Channel Power Indicator Lamp
- LCD screen
- Total Power Supply
Specification:
Model | PA-308PS |
| Description | PA System Power Supply Sequence Controller |
| Connect power supply | AC220V,50Hz |
| Channel | 8 channel +1 channel |
| Power output socket | Universal socket |
| Load capacity per channel | AC220V,16A |
| Complete load capacity | AC220V,40A |
| Channel timing delay | 1s |
| Multi-machine cascade control | Allow |
| Direct control | Sequence switch |
| External control | REM IN DC5V-12V , Status output |
| Serial port control | RS232 Db9 , 9600bps |
| Size | W483xD210xH50(mm) |
| Weight | 3.8kg |
Rear panel:
①Power Input AC220V,50Hz
②Universal socket output 1-8
③RS232 terminal,connecting PC and central control interface
④Cascading interface and wallboard control switch
