Zone Expansion Keypad (12 Zone) EVAC-12KD
The EVAC-12KD Zone Expansion Keypad is an extension to the EVAC-500RM Voice Alarm System Remote Microphone that adds additional zone-select keys. It has the same stable metal base as the call station. In addition to tabletop use, the special design allows it to be neatly flush-mounted in desktops.
Description:
The EVAC-12KD Zone Expansion Keypad is an extension to the EVAC-500RM Voice Alarm System Remote Microphone that adds additional zone-select keys. It has the same stable metal base as the call station. In addition to tabletop use, the special design allows it to be neatly flush-mounted in desktops.
Features:
- Each zone expansion keypad supports 12 zone selections.
- The keypad is used to expand the capacity of remote microphone for multiple-zones.
- Connecting one of these keypads to12 zones or zone groups that can be selected.
- Up to 11 keypads can be added to an EVAC-500RM Remote Microphone.
- LEDs on the keypad indicate the active zones.
- 12 zone selection keys and 12 zone selection LEDs
- Total system capacity of 120 zones.
- Keypad internal line will be monitored, fault will be indicated by LED and buzzer.
Specifications:
Model | EVAC-12KD |
| Description | Zone Expansion Keypad (36 Zone) |
| Power Consumption | 3W |
| Zone Capacity | 12 Zones |
| System Capacity | 11 units of keypads |
| Frequency Response | 80Hz~16kHz |
| THD | ＜1% at RMS,1KHz |
| S/N Ratio | >70dB |
| Operating Temp | -20℃ to +70℃ |
| Power Supply | DC5V, ±20% |
| Humidity | <95% no condensation |
| Dimension | 132(W)×150(H)×52(D) mm |
| Weight | 0.7kg |
