Digital Conference System Controller US-200MC

Features:

• Middle level digital conference system, featuring an 4.3 inch IPS screen and 1.5U rack-mount design, suitable for various ,conference scenarios including hotels, government agencies, enterprises, and multi-functional conference room;

• Supports analog bass, treble, and master volume adjustment; built-in DSP audio processing;

• 2 RCA LINE input, 2 RCA LINE input, 4 aviation connector inputs, and a dedicated microphone unit interface (4 aviation 8-pin male connectors);

• 1 XLR (male) LINE outputs, 2 RCA LINE output, and 1x6.35mm unbalanced output;

• Communication: 1 USB interface (for recording/USB flash drive MP3 playback), 2 RS232 interfaces, and 1 RS485/RS422 interface;

• Five 'Speaking Modes' can be set

• FIFO (First-In, First-Out) mode: Once the set number of speeches is reached, the first delegate unit to open is closed by the newly opened unit;

• Restricted Mode: After reaching the limit of speaking participants, there is a function for requesting to speak and be registered;

• Chairperson Mode: Only the chairperson can speak.

• Last in, first out mode: Once the set number of speeches is reached, the last activated speaking unit is closed by the newly activated one

• FREE Mode: Supports up to 12 delegate units simultaneously;

• Number of speakers: Can be set to '1-12' speakers

• ID Editing: Enter microphone ID editing mode via the SETID button on the rear pane;

• Supports 4-channel aviation 8-pin connectors, maximum number of microphones connected (daisy-chain, single channel = 25pcs mic, 4 channels = 100pcs mic) in T-type microphone connection mode;


Specification:
