IP Power Sequencer DI-9700ST
IP Audio SolutionsDI-9700ST series is one High Wattage IP Network Amplifiers from 850W, 1000W, 1500W to 2000W, which integrate 100V mixer amplifier, media player and IP audio decoder together. The IP network amplifier could be remotedly controlled by software. The IP network audio system will be used for long distance transmission to save much cable layout cost.
IP Audio Solutions
- Standard configuration: 1pcs 10/100M Rj45 network switch interface, supporting LAN and WAN
- Equipped with 8CH power management output interfaces, each interface can be manually or automatically opened,not interfering with each other. Using LED indicator lights to display the working status
- Adopting the concept of grid buffering control, equipped with fully open and fully closed buttons. When fully open,the open is in order from front to back, and when closed, the close is in order from back to front.Turn on each chancel power supply every 1 second interval
- With one control input and one control output.
- The total input power of the equipment is 6000W, and the maximum output power of each channel can reach 3000W.
- Designed using embedded computer technology.Adopting high-speed industrial grade chips with low startup time at 1 second.
- Support universal socket
- Support the upgrade of local area network and wide area network, which is convenient for effectively serving customers.
- Power supply AC 220V, 50Hz.
Mode | DI-9700ST |
Description | IP Power Sequencer |
Communication Protocol | TCP/IP、UPP，IGMP(multicast) |
Interface | RJ45 |
Sampling Rate | 16K-48KHz |
Control mode | Manual automatic transfer |
Input | 1CH control input |
Output | 1CH control output, AC 220V output |
Output power | 6000W |
Working temp | -20℃～+60℃ |
Humidity | 10% ~ 90% |
Power Consumption | ≤35W |
Power Supply | AC220V 50HZ |
Dimensions | 483*90*263mm |
Weight | 2.2Kg |
